XI Scenarios

The most common form of SAP EDI integration is performed using the SAP IDOC format, which is essentially a hierarchical flat file format developed by SAP. In other words, an IDOC is like a data file with a specified format which is exchanged between 2 systems which know how to interpret that data. IDOC stands for ' Intermediate Document' When we execute an outbound ALE or EDI Process, an IDOC is created. In the SAP System, I DOCs are stored in database.

Ar tonelico II: Melody of Metafalica is a RPG video game published by Gust, NIS America released on June 5, 2009 for the Sony PlayStation 2.iso CRC = 0D25B9E7 How to play with PCSX2 Emulator. Ar tonelico II: Melody of Metafalica is a RPG video game published by NIS America released on January 20, 2009 for the PlayStation 2. How to play with PCSX2 Emulator: Get the Latest version of PCSX2 and choose: System - Boot ISO. CoolROM.com's game information and ROM (ISO) download page for Ar tonelico II - Melody of Metafalica (Sony Playstation 2). Ar tonelico 2 melody of metafalica iso download.

IDoc to File Scenario

by Neeraja Surapaneni

1 General Requirement

The program also embeds your selected scroll speed and text size in the script file so you can save the file with different settings for different users or different project requirements. Ez reader teleprompter software.

1.1 Introduction

This document describes IDoc to file scenario in which an IDoc from an SAP system is converted into a Flat File and routed to the FTP Server via Exchange Infrastructure.

A business system representing Sender SAP system sends the IDoc to XI; XI converts the IDoc to Flat File and sends it to the receiving business system (FTP Server) by using an inbound File adapter.

1.2 Prerequisites:

• One Business System representing the sending R/3 is required to be configured of type 3^rd party in SLD (System Landscape Directory).
• FTP configuration should be in place to transfer the output file to desiredlocation.

2 Configurations at the Sender System (SAP R/3)

This section describes all the configurations needed in the Sender SAP System (R3X) for sending an IDoc to XIR.

2.1 Create RFC Destination

Use TCode SM59 to create RFC Destination in R3X to connect to XI (XIR) system.

RFC Destination in R3X: R3X_TO_XIR

2.2 Maintain Ports

Use TCode WE21 to create a tRFC Port. The RFC Destination created in the previous step should be assigned to this port.

Port in R3X: SAPXIR

2.3 Maintain Partner Profile

Create a Partner Profile for the Receiver System (XIRCLNT100) using the T-Code WE20, with the following outbound parameters.

Message type: MATMAS

IDoc Type: MATMAS05

Receiver port: SAPXIR

2.4 Create Distribution Model (BD64)

Create model view and add Message type with following

Sender System – R3XCLNT100

Receiver System – XIRCLNT100

Message type - MATMAS

Distribute the Model view.

3 Configurations in the Integration Server

This section gives an overview of all the configurations required in the Integration server. These settings are required for the XI system to receive the IDoc sent by the Sender SAP system.

3.1 Create RFC Destination

Use TCode SM59 to create an RFC Destination of Type 3 in order to establish communication with the Sender SAP system.

Sender RFC Destination in XIR: R3XCLNT100

3.2 Create Port

On the Integration Server, create a port for IDoc communication using transaction IDX1.

Ideally, the port name should be of the format SAPxxx, where xxx is the system id of the SAP system. The created port has to be bind with the RFC Destination of the Sender SAP system configured in the Step 3.1 above.

Sender Port in XIR: SAPR3X

3.3 Transaction IDX2

This configuration step is used to import the metadata of the IDoc using the corresponding Business system’s port as below.

continued.
